Cross Roller Guide Way

Guide

WRG

A compact and highly rigid linear guide where the roller cage rolls along the 90° V-grooves of the rail.

By mounting two rows of roller guides in parallel, it can withstand loads in all directions that are perpendicular to the axis.

Composed of a set of 4 dedicated rails and 2 roller cages.

Product Details
