Linear Motion Guide

Slim Linear Motion Guide – S…S Series

Rectangular, Short Type(RC)

– This is a slim, compact block with tapped holes on its top surface, and its width, height, and length have been minimized.

– It features a four-row circular structure with a 45° contact angle, providing equal load ratings in all four directions.

Product Details
